Measure Parts & Assemblies
Measure parts, assemblies, angles, and areas across more than 30 CAD formats directly in CAD ROOMS—no CAD license required. This video shows how to use smart snap markers for point-to-point distances, switch measurement units, adjust decimal precision, and inspect feature-specific dimensions in real time.
Key Video Chapters
- 00:05 — Access Measurement Tools for 30+ CAD Formats
- 00:22 — Use Smart Snap Markers for Point-to-Point Distances
- 00:32 — See Measurements Calculated in Real Time
- 00:38 — Switch Units and Adjust Decimal Precision
- 00:44 — Measure Angles, Areas, and Feature Dimensions
How to Measure a 3D CAD Model
- Open a CAD model. Find a part or assembly in your workspace and open it in the CAD ROOMS Viewer.
- Select the Measurement tool. Open the measurement tools to start measuring the 3D model.
- Measure distances. Select points or supported geometric features to measure distances, using snap markers to help position your selections.
- Adjust measurement settings. Change the measurement units and decimal precision as needed.
- Explore other measurements. Use the available tools to measure angles, areas, and other supported geometric features.
For detailed guidance, see How to Measure Parts and Assemblies.
